| Genset Model | YKDH-400ST |
| Rated power | 30kw |
| Rated speed | 1500r/min |
| Rated frequency | 50Hz |
| Rated voltage | 400V |
| Rated power factor | 0.8 |
| Phase | 3 phase 4 wire |
| Exciting mode | self-excitation |
| Voltage reguration mode | AVR automatic |
| Engine Model | WP2.3D33E200 |
| Rated power | 30KW |
| Rated speed | 1500r/min |
| Starting mode | DC12V electric |
| Type | 4 cylinders, in-line, direct injection, 4 stroke |
| Intake mode | Turbocharged |
| Bore*Stroke | 100*115mm |
| Oil model | CD15W/40GB11122 |
| Fuel consumption | 200g/kWh |
| Oil consumption | 1.5g/kWh(75% rated loading) |
| Cooling mode | Closed fan water cooling |
| Noise | 70Dba @7m |
| Welder Model | ZX7-400ST |
| Rated input power | 18.4kw |
| Rated input current | 28A |
| Rated input voltage | 36V |
| Rated output voltage | 40V |
| Output nonload voltage | 68/69/71V |
| Output current range | 20A--400A |
| TIG arc striking method | ST: contact arc |
| Protection class | IP21S |
| Insulation class | H |
| Overall dimensions | 1700 x 900 x 1300mm |
| Package dimensions | 1800 x 1000 x 1500mm |
Brand Cooperation:
Application area for your reference
Warranty Policy:
Guarantee for one year or 1000 hours (accord to whichever reach first) from ex-factory date.During the guarantee period,our company will provide the free easy damaged spare part for problems caused by our quality of production or raw material except the damageable spare parts of diesel engine caused by customer's incorrect man made operation.After expiration, our company provides cost parts maintenance for genset.
Packing Details:
Q:Are you a factory or a trading company?
A:We are factory.
Q:What kind of package do you use in delivery?
A:Less than whole container cargo,bubble film;whole container cargo, naked packing with plastic wrap.
Q:Can we customize the genset?
A:Yes,we can customize the color,style and configuration as your demands.
Q:What's your payment term?
A:We accept 30% T/T as the deposit,and balance payment before delivery.
Q:What's the delivery time?
A:Delivery within 7 days after deposit confirmed.
